ASTM A182 F316 2PC Ball Valve, 3 Inch, 300 LB, API 608, RF

Looking for a reliable ASTM A182 F316 ball valve supplier? We offer a 3-inch, 300 LB, DN80, PN50 ball valve that meets API 608 standards. Made from high-quality stainless steel with a bolted bonnet and two-piece design, our soft seal ball valve features an RF end and a convenient lever for easy operation.

Request a quote

Categories: Ball Valves
Tags: ASTM A182 F316 Ball Valve , 3 Inch Ball Valve , Class 300 LB Ball Valve

Detail Information

Ball valve, Stainless steel, bolted bonnet, NPS 3, 300 LB, F316, RF, FULL BORE.

Valve description:
Ball valve, Stainless steel, SOFT SEAL, TWO-pieces
Design: API 608.
Body: ASTM A182 F316
Nominal size: 3 Inch.
Nominal class: 300 LB.
End Connection: RF.
OPERATION: LEVER
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Stainless Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flange.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +300℃.

Technical parameters and characteristics

Product	Ball valve.
Nominal diameter	1/2 - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel.
Design standard	API 608.
Face to face	ASME B16.10.
OPERATION	GEAR, HANDLE
Connection end	BW, Flange.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
